GE Multilin D60 Line Distance Protection System 5-339
5 SETTINGS 5.7 CONTROL ELEMENTS
5
h) DIRECTIONAL COMPARISON BLOCKING1
PATH: SETTINGS  CONTROL ELEMENTS  PILOT SCHEMES  BLOCKING1 SCHEME
 BLOCKING1 SCHEME

BLOCKING1 SCHEME
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
BLOCK1 SCHEME BLOCK:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 RX CO-ORD PKP
DELAY: 0.010 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
TRANS BLOCK1 PICKUP
DELAY: 0.030 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
TRANS BLOCK1 RESET
DELAY: 0.090 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
BLOCK1 SCHEME SEAL-IN
DELAY: 0.010 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
BLK1 SCHME DIR FWD1:
Off
Range: FlexLogic operand
MESSAGE
BLK1 SCHME DIR FWD2:
Off
Range: FlexLogic operand
MESSAGE
BLK1 SCHME DIR FWD3:
Off
Range: FlexLogic operand
MESSAGE
BLK1 SCHME DIR REV1:
Off
Range: FlexLogic operand
MESSAGE
BLK1 SCHME DIR REV2:
Off
Range: FlexLogic operand
MESSAGE
BLK1 SCHME DIR REV3:
Off
Range: FlexLogic operand
MESSAGE
BLK1 FORCE TX STOP1:
Off
Range: FlexLogic operand
MESSAGE
BLK1 FORCE TX STOP2:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 SCHEME NO OF
COMM BITS: 1
Range: 1, 2, or 4
MESSAGE
BLOCK1 SCHEME RX1:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 SCHEME RX2:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 SCHEME RX3:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 SCHEME RX4:
Off
Range: FlexLogic operand
MESSAGE
BLOCK1 SCHEME TARGET:
Self-Reset
Range: Self-Reset, Latched, Disabled
MESSAGE
BLOCK1 SCHEME EVENTS:
Disabled
Range: Disabled, Enabled
