B.4 MEMORY MAPPING APPENDIX B
B
Fault Report Indexing (Read Only Non-Volatile)
3020 Number of Fault Reports 0 to 65535 --- 1 F001 0
Fault Report Actuals (Read Only Non-Volatile) (15 Modules)
3030 Fault Report 1 Time 0 to 4294967295 --- 1 F050 0
3032 Fault Report 2 Time 0 to 4294967295 --- 1 F050 0
3034 Fault Report 3 Time 0 to 4294967295 --- 1 F050 0
3036 Fault Report 4 Time 0 to 4294967295 --- 1 F050 0
3038 Fault Report 5 Time 0 to 4294967295 --- 1 F050 0
303A Fault Report 6 Time 0 to 4294967295 --- 1 F050 0
303C Fault Report 7 Time 0 to 4294967295 --- 1 F050 0
303E Fault Report 8 Time 0 to 4294967295 --- 1 F050 0
3040 Fault Report 9 Time 0 to 4294967295 --- 1 F050 0
3042 Fault Report 10 Time 0 to 4294967295 --- 1 F050 0
3044 Fault Report 11 Time 0 to 4294967295 --- 1 F050 0
3046 Fault Report 12 Time 0 to 4294967295 --- 1 F050 0
3048 Fault Report 13 Time 0 to 4294967295 --- 1 F050 0
304A Fault Report 14 Time 0 to 4294967295 --- 1 F050 0
304C Fault Report 15 Time 0 to 4294967295 --- 1 F050 0
Modbus File Transfer (Read/Write)
3100 Name of File to Read --- --- --- F204 (none)
Modbus File Transfer Values (Read Only)
3200 Character Position of Current Block within File 0 to 4294967295 --- 1 F003 0
3202 Size of Currently-available Data Block 0 to 65535 --- 1 F001 0
3203 Block of Data from Requested File (122 items) 0 to 65535 --- 1 F001 0
Security (Read/Write)
3280 Administrator Alphanumeric Password --- --- --- F202 (none)
Security (Read Only)
328A Administrator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
328B Administrator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
3295 Supervisor Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
329F Supervisor Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32A0 Supervisor alphanumeric password entry --- --- --- F202 (none)
Security (Read/Write Setting)
32AA Engineer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32B4 Engineer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32B5 Engineer Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32BF Operator Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32C9 Operator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32CA Operator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32D4 Observer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32DE Observer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32DF Observer Alphanumeric Password Entry --- --- 1 F202 (none)
Table B–10: MODBUS MEMORY MAP (Sheet 14 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
