B-52 D60 Line Distance Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7DE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
7DD0 ...Repeated for User Programmable Pushbutton 14
7E00 ...Repeated for User Programmable Pushbutton 15
7E30 ...Repeated for User Programmable Pushbutton 16
Distance (Read/Write Grouped Setting)
7E8C Distance Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7E8D Memory Duration 5 to 25 cycles 1 F001 10
7E8E Force Self-Polarization 0 to 4294967295 --- 1 F300 0
7E90 Force Memory Polarization 0 to 4294967295 --- 1 F300 0
Distance (Read Only)
7E94 AB Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7E96 AB Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7E98 AB Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7E9A AB Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7E9B BC Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7E9D BC Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7E9F BC Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EA1 BC Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EA2 CA Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7EA4 CA Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7EA6 CA Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EA8 CA Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EA9 AG Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7EAB AG Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7EAD AG Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EAF AG Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EB0 BG Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7EB2 BG Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7EB4 BG Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EB6 BG Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EB7 CG Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7EB9 CG Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7EBB CG Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EBD CG Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
Distance Loop Impedance (Read Only)
7EC0 Dist Zab Mag 0 to 655.35 ohm 0.01 F001 0
7EC1 Dist Zab Ang -359.9 to 0 degrees 0.1 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 44 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
