B-56 D60 Line Distance Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
8ED1 Trip Bus 1 Block 0 to 4294967295 --- --- F300 0
8ED3 Trip Bus 1 Pickup Delay 0 to 600 s 0.01 F001 0
8ED4 Trip Bus 1 Reset Delay 0 to 600 s 0.01 F001 0
8ED5 Trip Bus 1 Input (16 items) 0 to 4294967295 --- 1 F300 0
8EF5 Trip Bus 1 Latching 0 to 1 --- 1 F102 0 (Disabled)
8EF6 Trip Bus 1 Reset 0 to 65535 --- 1 F300 0
8EF8 Trip Bus 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8EF9 Trip Bus 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8EFA Reserved (8 items) --- --- --- F001 0
8F02 ...Repeated for Trip Bus 2
8F34 ...Repeated for Trip Bus 3
8F66 ...Repeated for Trip Bus 4
8F98 ...Repeated for Trip Bus 5
8FCA ...Repeated for Trip Bus 6
FlexElement (Read/Write Setting) (16 Modules)
9000 FlexElement 1 Function 0 to 1 --- 1 F102 0 (Disabled)
9001 FlexElement 1 Name --- --- --- F206 “FxE 1”
9004 FlexElement 1 InputP 0 to 65535 --- 1 F600 0
9005 FlexElement 1 InputM 0 to 65535 --- 1 F600 0
9006 FlexElement 1 Compare 0 to 1 --- 1 F516 0 (LEVEL)
9007 FlexElement 1 Input 0 to 1 --- 1 F515 0 (SIGNED)
9008 FlexElement 1 Direction 0 to 1 --- 1 F517 0 (OVER)
9009 FlexElement 1 Hysteresis 0.1 to 50 % 0.1 F001 30
900A FlexElement 1 Pickup -90 to 90 pu 0.001 F004 1000
900C FlexElement 1 DeltaT Units 0 to 2 --- 1 F518 0 (Milliseconds)
900D FlexElement 1 DeltaT 20 to 86400 --- 1 F003 20
900F FlexElement 1 Pickup Delay 0 to 65.535 s 0.001 F001 0
9010 FlexElement 1 Reset Delay 0 to 65.535 s 0.001 F001 0
9011 FlexElement 1 Block 0 to 65535 --- 1 F300 0
9013 FlexElement 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
9014 FlexElement 1 Events 0 to 1 --- 1 F102 0 (Disabled)
9015 ...Repeated for FlexElement 2
902A ...Repeated for FlexElement 3
903F ...Repeated for FlexElement 4
9054 ...Repeated for FlexElement 5
9069 ...Repeated for FlexElement 6
907E ...Repeated for FlexElement 7
9093 ...Repeated for FlexElement 8
90A8 ...Repeated for FlexElement 9
90BD ...Repeated for FlexElement 10
90D2 ...Repeated for FlexElement 11
90E7 ...Repeated for FlexElement 12
90FC ...Repeated for FlexElement 13
9111 ...Repeated for FlexElement 14
9126 ...Repeated for FlexElement 15
913B ...Repeated for FlexElement 16
Fault Report Settings (Read/Write Setting) (1 or 5 Modules)
9200 Fault Report 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
9201 Fault Report 1 Trigger 0 to 4294967295 --- 1 F300 0
9203 Fault Report 1 Z1 Magnitude 0.01 to 250 ohms 0.01 F001 300
9204 Fault Report 1 Z1 Angle 25 to 90 degrees 1 F001 75
9205 Fault Report 1 Z0 Magnitude 0.01 to 650 ohms 0.01 F001 900
9206 Fault Report 1 Z0 Angle 25 to 90 degrees 1 F001 75
9207 Fault Report 1 Line Length Units 0 to 1 --- 1 F147 0 (km)
Table B–10: MODBUS MEMORY MAP (Sheet 48 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
