B-58 D60 Line Distance Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
94A8 ...Repeated for Direct Input/Output 15
94B4 ...Repeated for Direct Input/Output 16
94C0 ...Repeated for Direct Input/Output 17
94CC ...Repeated for Direct Input/Output 18
94D8 ...Repeated for Direct Input/Output 19
94E4 ...Repeated for Direct Input/Output 20
94F0 ...Repeated for Direct Input/Output 21
94FC ...Repeated for Direct Input/Output 22
9508 ...Repeated for Direct Input/Output 23
9514 ...Repeated for Direct Input/Output 24
9520 ...Repeated for Direct Input/Output 25
952C ...Repeated for Direct Input/Output 26
9538 ...Repeated for Direct Input/Output 27
9544 ...Repeated for Direct Input/Output 28
9550 ...Repeated for Direct Input/Output 29
955C ...Repeated for Direct Input/Output 30
9568 ...Repeated for Direct Input/Output 31
9574 ...Repeated for Direct Input/Output 32
IEC 61850 Received Integers (Read/Write Setting) (16 Modules)
98A0 IEC61850 GOOSE UInteger 1 Default Value 0 to 429496295 --- 1 F003 1000
98A2 IEC61850 GOOSE UInteger Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
98A3 ...Repeated for IEC61850 GOOSE UInteger 2
98A6 ...Repeated for IEC61850 GOOSE UInteger 3
98A9 ...Repeated for IEC61850 GOOSE UInteger 4
98AC ...Repeated for IEC61850 GOOSE UInteger 5
98AF ...Repeated for IEC61850 GOOSE UInteger 6
98B2 ...Repeated for IEC61850 GOOSE UInteger 7
98B5 ...Repeated for IEC61850 GOOSE UInteger 8
98B8 ...Repeated for IEC61850 GOOSE UInteger 9
98BB ...Repeated for IEC61850 GOOSE UInteger 10
98BE ...Repeated for IEC61850 GOOSE UInteger 11
98C1 ...Repeated for IEC61850 GOOSE UInteger 12
98C4 ...Repeated for IEC61850 GOOSE UInteger 13
98C7 ...Repeated for IEC61850 GOOSE UInteger 14
98CA ...Repeated for IEC61850 GOOSE UInteger 15
98CD ...Repeated for IEC61850 GOOSE UInteger 16
FlexElement Actuals (Read Only) (8 Modules)
9900 FlexElement 1 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9902 FlexElement 2 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9904 FlexElement 3 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9906 FlexElement 4 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9908 FlexElement 5 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990A FlexElement 6 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990C FlexElement 7 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990E FlexElement 8 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
Breaker Restrike (Read/Write Setting) (3 Modules)
9930 Breaker Restrike 1 Function 0 to 1 --- 1 F102 0 (Disabled)
9931 Breaker Restrike 1 Block 0 to 4294967295 --- 1 F300 0
9933 Breaker Restrike 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
9934 Breaker Restrike 1 Pickup 0.10 to 2.00 pu 0.01 F001 500
9935 Breaker Restrike 1 Reset Delay 0 to 65.535 s 0.001 F001 100
9936 Breaker Restrike 1 HF Detect 0 to 1 --- 1 F102 1 (Enabled)
9937 Breaker Restrike 1 Breaker Open 0 to 4294967295 --- 1 F300 0
Table B–10: MODBUS MEMORY MAP (Sheet 50 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
