B-88 D60 Line Distance Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
33 Neutral Instantaneous Overcurrent 2
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
60 Negative Sequence Directional Overcurrent 1
61 Negative Sequence Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
101 Opposite Phase Rotation
112 Negative Sequence Time Overcurrent 1
113 Negative Sequence Time Overcurrent 2
120 Negative Sequence Overvoltage 1
140 Auxiliary Undervoltage 1
144 Phase Undervoltage 1
145 Phase Undervoltage 2
146 Phase Undervoltage 3
148 Auxiliary Overvoltage 1
151 Phase Overvoltage 1
152 Phase Overvoltage 2
153 Phase Overvoltage 3
154 Compensated Overvoltage 1
156 Neutral Overvoltage 1
160 Phase Distance Zone 1
161 Phase Distance Zone 2
162 Phase Distance Zone 3
163 Phase Distance Zone 4
164 Phase Distance Zone 5
168 Line Pickup
172 Ground Distance Zone 1
173 Ground Distance Zone 2
174 Ground Distance Zone 3
175 Ground Distance Zone 4
176 Ground Distance Zone 5
180 Load Encroachment
190 Power Swing Detect
214 Sensitive Directional Power 1
215 Sensitive Directional Power 2
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
228 SRC5 VT Fuse Failure
229 SRC6 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
242 Open Pole Detector
Bitmask Element
280 Breaker Failure 1
281 Breaker Failure 2
282 Breaker Failure 3
283 Breaker Failure 4
288 Breaker Arcing Current 1
289 Breaker Arcing Current 2
290 Breaker Arcing Current 3
291 Breaker Arcing Current 4
292 Breaker Arcing Current 5
293 Breaker Arcing Current 6
294 Breaker 1 Flashover
295 Breaker 2 Flashover
311 Phasor measurement unit one-shot
312 Synchrocheck 1
313 Synchrocheck 2
336 Setting Group
337 Reset
344 Overfrequency 1
345 Overfrequency 2
346 Overfrequency 3
347 Overfrequency 4
352 Underfrequency 1
353 Underfrequency 2
354 Underfrequency 3
355 Underfrequency 4
356 Underfrequency 5
357 Underfrequency 6
360 Trip Output
362 Phase Selector
363 Open Pole Detector
365 Directional Comparison Unblocking Scheme
366 DUTT Pilot Scheme
368 PUTT Pilot Scheme
370 POTT Pilot Scheme
371 POTT1 Pilot Scheme
372 Hybrid POTT Pilot Scheme
374 Directional Comparison Blocking Pilot Scheme
388 Selector 1
389 Selector 2
390 Control pushbutton 1
391 Control pushbutton 2
392 Control pushbutton 3
393 Control pushbutton 4
394 Control pushbutton 5
395 Control pushbutton 6
396 Control pushbutton 7
400 FlexElement 1
401 FlexElement 2
402 FlexElement 3
403 FlexElement 4
404 FlexElement 5
405 FlexElement 6
406 FlexElemen 7
Bitmask Element
