D-4 D60 Line Distance Protection System GE Multilin
D.1 IEC 60870-5-103 APPENDIX D
D
 <75> Fault reverse/busbar
 <76> Teleprotection signal transmitted
 <77> Teleprotection signal received
 <78> Zone 1
 <79> Zone 2
 <80> Zone 3
 <81> Zone 4
 <82> Zone 5
 <83> Zone 6
 <84> General start / pick-up
 <85> Breaker failure
 <86> Trip measuring system L
1
 <87> Trip measuring system L
2
 <88> Trip measuring system L
3
 <89> Trip measuring system E
 <90> Trip I>
 <91> Trip I>>
 <92> Trip IN>
 <93> Trip IN>>
Auto-reclosure indications in monitor direction
INF Semantics
 <128> CB ’on’ by AR
 <129> CB ’on’ by long-time AR
 <130> AR blocked
Measurands in monitor direction
INF Semantics
 <144> Measurand I
 <145> Measurands I, V
 <146> Measurands I, V, P, Q
 <147> Measurands I
N
, V
EN
 <148> Measurands I
L123
, V
L123
, P, Q, f
Generic functions in monitor direction
INF Semantics
 <240> Read headings of all defined groups
 <241> Read values or attributes of all entries of one group
 <243> Read directory of a single entry
 <244> Read value or attribute of a single entry
 <245> End of general interrogation of generic data
 <249> Write entry with confirmation
 <250> Write entry with execution
