ā€“ 28 ā€“
Electric Model
Component Locator Views
(Continued Next Page)
Power Board
High Limit Thermostat
Inlet Safety Thermostat
Triac
Dual Idler Pully
Drum Motor
Blower Motor
(behind frame)
Blower Wheel
Rack Dry Thermostat (behind frame)
Outlet Control Thermistor (behind frame)
Outlet Control Backup Thermostat
Inlet Control Thermistor
Fuses
Rack Dry
Interlock
Relay
Heater Assembly
