A
131
Specifications
Feature Specification
Power
AC 100 – 240 V, 50 – 60 Hz; 115 V, 400 Hz
DC (optional battery) 11 – 16 V
Maximum consumption 300 W
Nominal consumption 150 W (when not charging battery or using accessories)
Battery operation Up to one hour (small battery) or two hours (large battery)
AC output IEC-type F connector. The voltage and frequency of the power available at the
AC output is the same as the voltage and frequency applied to the inlet. Maximum
output is 100 W.
Arc lamp 75-watts, high-intensity discharge (HID)
Fuses
AC :6.3A, 250V, fast acting
DC 20A, 600 VDC, fast acting
Operating environment
System operating temperature -4° to 115°F (-20° to 46°C)
LCD requires warm-up period below 32°F (0°C) .
Tip operating temperature -13° to 176°F (-25° to 80°C)
Reduced articulation below 32°F (0°C)
Storage temperature -13° to 140°F (-25° to 60°C)
Relative humidity 95% max, non condensing
Waterproof: Insertion tubes are watertight to 1 bar (14.5 psig, 10.2 m [33.5 ft] of H
2
O)
Hazardous Environments Not rated for use in hazardous environments
System
Case Dimensions Standard: 54.6 x 49.5 x 32.0 cm (21.5 x 19.5 x 12.6 in)
Tall: 54.6 x 60.9 x 32.0 cm (21.5 x 24 x 12.6 in)
Weight In Case: 21.8 kg (48 lb)
Without Case: 10.9 kg (24 lb)
QuickChange™ Probes
6.1 mm (0.242 in), 5.0 mm (0.197 in) and 8.4 mm (0.331 in) Diameter Probes
Image Sensor 1/6” Color SUPER HAD CCD®
Pixel Count 440,000 pixels
Temperature Sensor Integrated Temperature Warning System
