GE Fuji Electric FVR-C9S-2UX Series - Page 13

12
FVR-C9S-2UX
5.04 (128)
2 - dia. 0.20
(2 - dia. 5)
0.24 (6.2)
0.71 (18)
0.24 (6.2)
FVR005C9S-2UX
0.24 (6.2)
0.45 (11.5)
TERMINAL M4
3.37 (85.5)
0.24 (6.2)
0.24 (6.2) 5.45 (138.5)
2.87 (73)
0.24 (6.2)
5.61 (168) 5.18 (157)
5.51 (140)
7.09 (180)
0.20 (5)
2.01 (51)5.08 (129)
0.24 (6.2)
0.45 (11.5)
0.45 (11.5)
0.43 (11)
4.61 (117)
0.45 (11.5)
3.78 (96.1)0.47 (12)
2.58 (65.5)
2.09 (53)
0.49 (12.5)
External Dimensions cont.
