21 /

9/23/2012

Specs:

120 Volt AC Components

• Circulation Pump: 120 VAC, .8 amp – 3.8 LRA, 8GPM @ 5PSI

• Drain Pump: 120 VAC, 27 ohms, .65 amp

• Heater: 120 VAC, 18 ohms wet – 23.4 ohms dry, 6.7 amp wet - 5.125

Watts, 800 wet / 650 dry +/- 5%

• Tub TCO: 120 VAC, 210f +/- 10 Manual Reset

• Main Control: 120 VAC / 5 & 13.5 VDC

DC Volt Components

• UI Control: 13.5 VDC input, 13.5 volts DC output (some models)

• Door Switch: 13.5 VDC

• Water Valve: 13.5 VDC, 32 ohms, .83 GPM

• Detergent Cup: 13.5 VDC , 32 ohms

• Turbidity Sensor: .24-3.8 VDC, 10K ohms

• Flood Switch: 13.5 VDC, .42 amp

• Thermistor (in flood switch): Resistance Temperature

20K 50

11K 75

5.8K 100

3.4K 125

2.1K 150

1.3K 175
