Service Mode: As past models, Service mode can be used to control
Loads for component testing.
To enter Service mode, the Error Code Mode must be active.
Select
Cycle
Select
Cycle
Start
Blinks of
Normal LED
Load To Control Timeout / Notes
1 Drain Pump Attempts to automatically drain the tub to empty.
From target level, takes approximately 2 minutes.
2 Water Valve Attempts to automatically fill the tub to the target volume.
To the target level, this takes approximately 60 seconds.
3 Circulation Pump Changes the spray arm (via changing diverter) every 30
seconds. Runs for a maximum of 2 minutes.
4 Heater Turns the heater on for a maximum of two minutes.
5 Detergent Module Turns the soap dispense solenoid on for a maximum of 15
seconds.
Press and hold
5 seconds
Selects/Increments
Test
Start/Stop Test
*Press any button except Select Cycle or Start to exit
*Will time out after 5 minutes
