Detergent Modul
e
•
Detergent
Cup and Rinse
Aid is activated by
solenoid
•
13.5 volt
s DC
•
32 Ohms
•
GDT550H has
a Rins
e
Aid dispenser
tank sensor
.5 second
activation of
solenoid releases
the detergent
cup
15 second
activation of
solenoid releases
rinse aid
•
Use Service Mode
to test the
deterg
ent
Module
T
o Remove
Detergent
Module
1.
Remove and
separate
Door
2.
Remove 6
-
¼” hex
head
screws
53
55
