UI Board
• Top Control Indicator LED on front panel, amber when
running, green when cycle complete.
• GDF510P only, has Logic programed in the Main Control
Board. All other models have Logic programed in the UI
Board
• Use Service LED on Main Control to aid diagnoses (see
Service LED table for details)
