Sump Module removal

• Remove Power to Dishwasher

• Remove Toe Kick

• Remove door

• Disconnect Drain Line, ¼” hex head worm gear clamp

• Disconnect wire harness to Turbidity sensor (some models)

• Disconnect wire harness to flood switch, this step can be done after

sump is pushed into tub if access is hindered.

• Release 3 sump latches (rotate to stop point)

• Push pump module up and into the tub

• Remove Wash Pump and Drain Pump Shields

• Remove wiring to Flood Switch, Wash Motor and Drain Pump

• Remove wire to heat element to allow wire harness removal from sump

module

Note:

• Shields must be re-installed

• When reinstalling press sump in from top to seat and latch the sump

clips (do not use sump clips to seat the sump)
