Dishwasher Installation
LITERATURE
• Be sure to leave complete literature package, these Installation
Instructions and product samples and/or coupons with the
consumer.
REPLACE TOEKICK
• Place toekick against the legs of the dishwasher.
• Align the toekick with the bottom edge and make
sure it is against the floor.
• Insert and tighten the 2 toekick attachment screws.
The toekick should stay in contact with the floor.
Tip: Reduce sound from under the dishwasher.
Make sure toekick is against floor.
Figure AJ
Attachment
Screws
Toekick
CHECK THE FOLLOWING
• Tub trim does not interfere with the door
• Dishwasher is square and level at both the top and
bottom of the cabinet opening, with no twisting or
distortion of the tub or door
• On models without the adjustable leveling system,
make sure all 4 legs of the dishwasher are firmly in
contact with the floor
• On models with the adjustable leveling system, make
sure both front legs of the dishwasher and the center
rear leveling system leg are firmly in contact with the
floor
• Drain hose is not pinched between the dishwasher
and adjacent cabinets or walls
• Tub trim is fully seated on the tub flange
STEP 22
STEP 23
STEP 24
15
