Disassembly – Drum Support & Drum(2)
34
Removal:
5. Lift drum support upwards
slightly to release tab at each
arm.
6. Reach behind drum support
after releasing from side panel.
With needle nose, squeeze
back side of the four wire
clamps (two on either side of
drum support.
7. Remove drum support from
machine and set aside.
