GE GFE29HSDASS

50
5/4/2012
Fresh Food Fan Removal
¾ Disconnect the motor harness
connector.
¾ Pull the Styrofoam cover out from
the lower left corner and remove.
¾ Slide the fan assembly
forward and out of the
fan mounting bracket.
FAN color code:
RED – 12vdc+
BLACK – 12 VDC-
YELLOW – PWM SPEED
BLUE – RPM FEEDBACK
