Description and operation
General description of the circuit- b reaker
GE Information L12- 039EN/03
3/6
03- 2017
Bearing structure
Description
The support- frame (10) - made up with four supports fastened to the housing
(3) - supports all the circuit- breaker components.
The support- frame may be supplied by either Grid Solutions or the custom-
ers.
Diagram
10
3
