Installation Instructions
• Place 2-piece toekick against the legs of the dishwasher.
• Place the inner toekick piece (with slots) against the
toekick bracket. The slots should align with toekick
bracket screw holes. Allow the toekick to touch the floor.
• Place larger toekick over the inner piece and install 4
toekick screws.
• Use additional 2 screws for installations over
33-1/2" high.
• Use both toekick pieces for all installation heights.
Figure Z
STEP 17 REPLACE TOEKICK
STEP 16 DISHWASHER WET TEST
Turn on power supply (or plug power cord into outlet, if
equipped).
Turn dial to Normal “Wash” position.
Close door.
Check to be sure that water enters the dishwasher. If
water does not enter the dishwasher, check to be sure that
water and power are turned on.
Check for leaks under the dishwasher. If a leak is found,
turn power supply off, then tighten connections. Restore
power after leak is corrected.
Check for leaks around the door. A leak around the door
could be caused by door rubbing or hitting against adjacent
cabinetry. Reposition the dishwasher if necessary.
See Step 9.
The dishwasher will drain and turn off about 5 to
7 minutes after the first fill. Check drain lines.
If leaks are found, turn power off at the breaker and correct
plumbing as necessary. Restore power after corrections are
made. See Step 12.
Open dishwasher door and make sure most of the water has
drained. If not, check that disposer plug has been removed
and/or air gap is not plugged. See Step 13. Also check drain
line for kinking.
Run the dishwasher through another fill and drain cycle.
Check for leaks and correct if required.
At the end of drain, open door and turn dial to OFF position.
350A4502P436
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
STEP 18 LITERATURE
Be sure to leave complete literature package and
installation instructions with consumer.
2-Piece Toekick
Adjust Up
or Down
Use Top 4
Screw Holes
