GE GTD33EASKWW Installation Instructions

Installation Instructions
18
A
REVERSING THE DOOR - SOLID DOOR
MODELS (cont.)
5
Mount the door on the 2 upper left side hinge screws
installed in step 2. Move the hinge screws loosened in
step 3 into the lower left side screw holes and firmly
tighten all 4 screws.
6
Install the 4 plastic caps removed in step 1 into the 4
right side front panel holes.
NOTE: To return the door to the original setup, follow
these instructions, swapping “left” and “right”.
When you finish
Plug the dryer back into
its electrical outlet.
Door
Hang door and
tighten screws
Plastic Cap (4)
Right side of
front panel
REVERSING THE DOOR (cont.)

GE GTD33EASKWW Specifications

General

Capacity	7.2 cu. ft.
Fuel Type	Electric
Drum Material	Aluminized Alloy
Heat Selections	4
Color	White
Timed Dry	Yes
Wrinkle Care Option	Yes
Drum Light	No
Energy Star Certified	No
Dimensions (HxWxD)	44 x 27 x 29.5 inches
Vent Type	Rear
