Wire
Connecter
Pressure Hose
Pressure Sensor
Location and Removal
The pressure sensor is
located in the backsplash
area. Remove backsplash
assembly.
Compress the locking tab
holding the sensor in its
housing.
Disconnect the sensor wire
connector and the pressure
hose.
54
