Performance specifications
Provide Smart Patient and Staff/Duty Stations at the locations
specified. The Smart Patient and Staff/Duty Stations install on
a 3-gang plaster ring and use a snap-together design with no
visible mounting screws after the unit has been installed. All
terminations on the Smart Patient and Staff/Duty Stations are
on RJ-45 connectors. All addressing of the Smart Patient and
Staff/Duty Stations is automatic using an intelligent addressing
scheme and does not require any manual addressing using DIP
switches at the station location. The Smart Patient and Staff/
Duty Stations have a NiteLite feature for visibility in dark rooms.
The Smart Patient and Staff/Duty Station buttons are software-
configurable and have field-replaceable button labels using a
label insert behind the clear button membrane.
Each Smart Patient and Staff/Duty Station is molded from
Cycoloy
®
. A central Telligence Station Gateway supplies all
power for the Smart Patient and Staff/Duty Stations.
Three of the buttons on the Patient or Staff/Duty Station may
be configured in the field for different functions depending on
the need. Customizable labels simply slide behind the switch
membrane. Switch functions are set on the Telligence network
with software programming tools.
Users operate the station by pressing one of the buttons on
the front of the unit. Calls may also be placed by operating a
connected call cord or pillow speaker.
Typical station functions include:
CODE: This button initiates a code blue call that activates
the corridor light and is displayed on the Staff Console or
Annunciator. The system can be configured to automatically
page a predetermined staff when this button is pressed
EMERG: When this button is pressed a staff emergency call
goes out to the staff console or annunciator and activates the
corridor light accordingly.
ASSIST: This button initiates a normal priority call that is
displayed on the staff console or annunciator and the corridor
light is activated accordingly.
CANCEL: This button clears all active calls registered at the
station.
LEDs adjacent to each button on the Patient or Staff/Duty
Station indicate the type of call that is placed. Additional LEDs
indicate the status of auxiliary hardware and, for dual patient
stations, provide visual cues concerning which bed the call
originated from. All stations feature NiteLite technology for easy
visibility under low ambient light conditions.
Smart Patient and Staff/Duty Stations feature an ingenious
cleaning mode that helps to prevent false calls on the system.
When the station is idle, pressing the CANCEL button for
between two and four seconds temporarily disables the front
panel buttons. This allows maintenance personnel to clean the
unit without fear of accidentally placing a call.
Power specifications
Electrical rating
Single Smart Patient Station 40 VDC, 1.9 W
Smart Staff/Duty Station 40 VDC, 1.9 W
Dual Smart Patient Station 40 VDC, 2.2 W
Power source Telligence Station Gateway
Physical specifications
Dimensions 11.4 x 17.5 x 5.8 cm
(HxWxD) (4.5 x 6.9 x 2.3 in)
Mounting Wall mounting, 3 gang ring on a
non-masonary box.
Construction Cycoloy
Flammability rating 94 V-0
Terminations RJ-45, plus lever-type connectors for
TV/Lighting control options
Indicators LEDs for CODE, EMERG, CANCEL, ASSIST
IP address None
requirements
Audio input Microphone
Audio output Speaker for full-duplex intercom
Controls Buttons for CODE, EMERG, CANCEL, and
ASSIST
Certifications
UL, CSA (22.2 No. 205-M1983)
85100-0104; DOC0636754 Rev. 4 (page 3 of 4)
Ordering information
Smart Patient and Staff Duty Stations
Model # Description Shipping weight
HC-PSTN1 Single Smart Patient Station 0.41 kg (0.90 lb)
HC-PSTN2 Dual Smart Patient Station 0.41 kg (0.90 lb)
HC-CCPSTN Call Cord Smart Patient Station 0.41 kg (0.90 lb)
HC-DUTY Smart Staff/Duty Station 0.41 kg (0.90 lb)
HC-AP-W-4G/3G Adaptor plate, white 4-gang to
3-gang
0.23 kg (0.50 lb)
HC-AP-W-6G/3G Adaptor plate, white 6-gang to
3-gang
0.23 kg (0.50 lb)
