Chapter 1 Introduction
Chapter 1. Introduction
The QuickPanel+ operator interface is an all-in-one microcomputer designed for maximum
flexibility. The design, based on an advanced ARM core microprocessor, brings together a
high-resolution touch-screen operator interface with a variety of communications options. You
can connect to most industrial equipment through the QuickPanel+ communications ports.
The QuickPanel+ is equipped with several memory types to satisfy the most demanding
applications. A 512MB section of DRAM is split between the operating system, an object
store and application memory. Functioning as a virtual hard drive, a 256MB section of non-
volatile flash memory is divided between the operating system and persistent storage for
application programs. The retentive memory consists of 512KB of battery-backed SRAM for
data storage, protecting your valuable data during a power failure.
1.1 Specifications
1.1.1 General Specifications
Processor
Freescale i.MX535 (1GHz ARM Cortex A8)
Memory
RAM
DDR2 SDRAM 512MB
ROM
SLC NAND 256MB
SRAM
512 KB (with Battery backup)
Operating system
Microsoft Windows Embedded Compact 7
Display
Type
7” Widescreen TFT LCD
Resolution
800(W) x 480(H) pixels WVGA
Backlight
LED
Touch screen
Touch Panel Type
Projected Capacitive
Multi-touch
Two-point
Communications
Ethernet Port
1x 10/100BaseT (RJ-45)
Serial Port
1x RS-232 UART Port (5-Pin Connector)
USB, Host
Two USB2.0 (Type-A)
Max. Power (5V @ 0.5A)
USB, Device
One USB 2.0 (Mini Type-B)
Storage
One SD/SDHC Card Slot
Audio
One Mic In (mono) (3.5mm Jack
One Line Out (Stereo) (3.5mm Jack)
Noise immunity
Noise voltage: 1500V p-p
Pulse Duration: 1µs, Rise time: 1ns
Input power
Maximum Rated
Voltage
+30VDC
Rated Voltage
+24VDC ±20% (3-Pin Connector)
Power Consumption
15W (max)
Frame Ground
Frame GND is connected to Signal GND internally
