GE IM4A - Ice Maker

8
Installation Instructions
CONTENTS OF KIT IM-4A
Owner’s Manual &
Installation Instructions
2
Ice Bucket
9
Water Line Clamp
(strain relief), for
house water line
6
Hex-Head Screw
for Water Line Clamp
5
Water Valve and
Tube Assembly
3
Hex-Head Screw, for
attaching water valve
10
Adhesive-Backed Water Tube
Fasteners, to secure plastic
water tube (4)
4
12
Water Tube Inlet
11
Phillips Head Screws,
for mounting icemaker (2)
Warranty Label
7
ICEMAKER
WARRANTY VERIFICATION
Date Installed
Dealer
Fill Tube Extension
(3/4″ O.D.)
8
15
Fill Tube
(5/8″ O.D.)
13
Fill Tube with Foil
(5/8″ O.D.)
14
Icemaker Fill Cup
(side-mounted)
Icemaker
1
I
n
s
t
a
l
l
a
t
i
o
n
I
n
s
t
r
u
c
t
i
o
n
s
16
Hose Clamp
Water Tube
Inlet Cover
17
Hex-Head Screws, for
attaching water tube
inlet cover
18
