GE IM4D - TROUBLESHOOTING; Automatic icemaker does not work

20 49-60698-4
Troubleshooting Tips... Before you call for service
6DYHWLPHDQGPRQH\5HYLHZWKHFKDUWVRQWKHIROORZLQJSDJHVILUVWDQG\RXPD\QRWQHHGWRFDOOIRUVHUYLFH,I
QHHGHGVHUYLFHFDQEHVFKHGXOHGE\YLVLWLQJXVRQOLQH*($SSOLDQFHVFRPRUFDOOLQJ*(&$5(6
,Q&DQDGDYLVLW*($SSOLDQFHVFDRUFDOO
Problem Possible Causes What to Do
Automatic icemaker
does not work
Freezer compartment too warm. After installing the kit, allow the refrigerator to
completely cool down for 24 hours. Once the
compartment is cool, the icemaker will begin ice
production.
Icemaker is not turned on. 0RYHWKHLFHPDNHUSRZHUVZLWFKWRWKH21
position.
Icemaker is not plugged in
correctly.
Check that the
icemaker cord plug
is fully inserted into
the socket. See
3OXJLQWKH
LFHPDNHULQWKH
,QVWDOODWLRQ
,QVWUXFWLRQV
Water line kinked. Check that the plastic
water line running
from the valve to the
water tube inlet is not
NLQNHG6HH&RQQHFW
WKHZDWHUOLQHLQWKH
,QVWDOODWLRQ
,QVWUXFWLRQV$NLQNLQ
the water line will
restrict flow to the
water line.
Water supply turned off or not
connected.
After installing the kit, make sure the house water
supply to the refrigerator has been turned on.
Piled up cubes in the storage bin
cause the icemaker to shut off.
/HYHOFXEHVE\KDQG
Water valve is not plugged in
correctly.
Check that the valve wire adapter is completely
plugged onto the terminals on the water valve.
6HH$WWDFKWKHZDWHUYDOYHLQWKH,QVWDOODWLRQ
,QVWUXFWLRQV
Feeler
Arm
Power
Switch
,FHPDNHU
(Appearance may vary)
&OLS5HVWUDLQWVRQWR
/RFNLQJ7DEV
/RFNLQJ
Tabs
Hook
Adhesive-backed
Fasteners for
Water Tube
Adapter
Valve Terminals
TROUBLESHOOTING TIPS
