PLUG IN THE ICEMAKER
Holding the icemaker in place, insert the
icemaker power cord plug into the socket on
the side wall, making sure the prongs and holes
are matched. Press
the plug firmly into the
VRFNHW/RFNWKHSOXJLQ
place by clipping the
restraints onto each side
RIWKHSOXJ0DNHVXUHWKH
restraints click into place.
0DNHVXUHWKHSRZHUFRUG
is still in the hook on the
back of the icemaker.
INSTALLATION INSTRUCTIONS
Hook
Installation Instructions
ICEMAKER INSTALLATION INSTRUCTIONS (Continued)
9
MOUNT THE ICEMAKER
Ɣ/LIWWKHLFHPDNHUVRWKH fill tube assembly
RUGHSHQGLQJRQPRGHOILWVLQWKHfill
cup opening'+DQJWKHLFHPDNHURQWKH
two mounting screws%
Make sure:
Ɣ The power cord is still firmly in the socket.
Ɣ7KHfill tube assemblyRUGHSHQGLQJ
on model) extends into the fill cup opening
DWWKHEDFNRIWKHLFHPDNHU&KHFNWKHUHDU
of the refrigerator to make sure the fill tube
has not been pushed out of the back of the
refrigerator).
Ɣ7KHLFHPDNHUPRXQWLQJVFUHZVDUHORFDWHGLQ
the uppermost position of the mounting slots
on the icemaker bracket.
Ɣ7KHLFHPDNHULVOHYHO
Ɣ7KHLFHPDNHUSRZHUVZLWFKLVLQWKHOFF
position.
SECURELY TIGHTEN THE ICEMAKER
MOUNTING SCREWS.
11 12
D
B
10
INSTALL THE ICE BUCKET
Place the ice bucket
under the icemaker.
11
ATTACH WARRANTY LABEL
A labelLVSURYLGHGZLWKWKLVNLWWRUHFRUGWKH
date of installation for warranty purposes. Apply it
to the back of the refrigerator.
12
KEEP THIS MANUAL
The warranty for the icemaker is printed in
this manual. Keep this manual with your
Refrigerator Owner’s Manual.
The icemaker installation inside the freezer is
now complete. Continue to the Water Valve
Assembly section on page 12.
