Route separately EMI filter incoming power lines and outgoing power lines (refer
to
Electrical Connections
).
NOTE: The maximum distance between the EMI filter and the PDB is 3 m.
NOTE: The Fluoro UPS option requires an EMI filter placed upstream the PDB. The EMI filter
will be delivered with the Fluoro UPS. According to the country, filter enclosure and
additional protective device can be supplied either by GE Power Control and by GE
Industrial System. For further information on the EMI filter, see
Typical EMI Filter
Enclosure
in Chapter 6, Section 2, Recommended Power Distribution System
2.5 Radiation Protection
Because x–ray equipment produces radiation, special precautions may be needed or special site
modifications may be required. The General Electric Company does not make recommendations
regarding radiation protection. It is the purchasers’ responsibility to consult a radiation physicist
for advise on radiation protection in x–ray rooms.
2.6 Audible noise
•
Less than 50 dB (A) at 1 meter for an Innova LC Positioner.
•
Limited to 50 dB (A) at 1 meter for Omega IV, Omega V tables.
•
Limited to 58 dB (A) at 1 meter for Innova
IQ
Table.
•
Limited to 55 dB (A) at 1 meter for C2 Cabinet.
•
Limited to 60 dB (A) at 1 meter for the COOLIX 4000.
•
Limited to 65 dB (A) at 1 meter for C1 Cabinet.
•
Limited to 60 dB (A) at 1 meter for Digital Detector Chiller Thermo–Tek.
•
Limited to 52 dB (A) (background of 35 dB (A)) at 1 meter for Digital Detector Chiller Thermo–
Con.
•
Less than 50 dB (A) at 1 meter for a DL LCD monitor.
•
Less than 60 dB (A) at 1 meter for the Fluoro UPS.
NOTE: Both cabinets C1 and C2 generate 70 dB noise altogether. Noise can be reduced if
cabinets are slightly separated, and as far as possible from Exam room.
2.7 Windows and curtains
When the examination room has a window with an aperture outside of the controlled light area
(day light, other...) a curtain has to maintain the light intensity under a limit fixed to 150 lux.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 3 Physical Requirements of Room 65
