GE Keypad Controller 45631 - Page 3

Multi-color LED (Green/Orange/Red)
(behind bezel). Visible only when the
device is in setup mode
Amber LEDs behind
buttons provide
visual feedback
Turns selected
Group or Scene ON
Press & Release to
change to Scene
mode
After entering
SETUP mode, use
to Remove devices
from a Group or
Scene
Group Scene
Add
Remove
Group/Scene buttons are numbered only
in the instructions. The buttons on the
device are not numbered.
1
2
3
4
