4
INSTALLATION
Select an existing light fixture, either wall or eave mount for replacement.
Note: The fixture must be connected to 120v, 60Hz power source.
MOUNTING PREPARATION FOR THE LED LIGHT FIXTURE
Note: For maximum flexibility, the LED Security Light can be mounted on a
wall (vertical) or under the eave (horizontal).
Eave Mount
Wall Mount
LED Housing
Lock Nut
Motion
Sensor
Adjustment Knob
Cover
Housing
Mounting
Plate
Time Adjustment
for Lights
Dusk/Dawn
Adjustment
