g
Product Data Sheet – rev 4.2
July 4th 2003
Page 15
LightSpeed
With Xtream
CT Scanner System
GE Medical Systems-America
Milwaukee, USA - Fax: 1 414 544 3384
GE Medical Systems-Asia:
Tokyo, Japan - Fax: 81 425 85 5490
Hong Kong - Fax: 852 2559 3588
GE Medical Systems-Europe
Temperature Rate of Change: 3°C/hour max.
•
72 Hz Vertical deflection frequency • Easy-to-use calcium scoring software
with integrated patient report generation
• Sync on green
Relative Humidity Rate of Change: 5%
RH/hour max.
• Snapshot Option (B7710LS)
• LCD Color Monitor*: 18” diagonal width
• CT Perfusion 2(B7700PL)
• Scan control keyboard (English language)
assembly with intercom speaker,
microphone and volume controls.
Power Requirements:
• Smart Step (B7868WL) – SW
The only facility input to the system is a 380 to
480 V nominal, 3 phase Delta or Wye, 50/60
Hz, 90 kVA service, 20 kVA average power;
main disconnect to be located within 5 feet
(1.5 m) of the PDU. The facility must also
provide a protective disconnect device with
low voltage, low energy local and multi-point
remote capability, in the line feeders to the
PDU.
• Smart Step HW (B7868SM & B7868SN)
• Global modem to allow InSite connectivity
• Advanced Vessel Analysis (B7868LA)
• 3-Button Mouse
• CT Colonoscopy (B7868LC)
• 3-Button Trackball
• CardIQ2 (B7710LR)
• Remote 21 inch Color Monitor (B7530RC)
Image Networking:
• Exide UPS (B7999PS)
• Standard auto-configuring
100BaseT/10BaseT Ethernet (UTP
connection)
• Metal Free Table Interface for 3
rd
Party
Attachments (B7999PM)
Complete, detailed specifications of all power
requirements are available upon request. For
most installations, the Lightspeed
16
CT
Scanner System does not require any power
conditioning equipment to be used in
conjunction with the PDU. Regulators are not
recommended for use with this system. For
those sites with known large power line
transients, a suppresser filter for the system
computer and peripherals may be useful. In
general, suppresser filters are not
recommended.
• LCD Monitor (B7858LC)
• Direct network connection; multi-suite
ethernet card not required for gateway out of
suite
• GE Color Printer (E7014LA)
• Table Tray
• Protocols supported:
• DICOM 3.0 network send (one IP
address at a time) and receive,
pull/query, and storage commitment
push;
Siting Requirements
Minimum Suite Size:
• AdvantageNet (GenesisNet) point-to-
point send, receive and pull/query (no
broadcast);
Overall Suite:
Compatible UPS options are available if
desired.
15.5 feet (4.74 m) wide x 19.5 feet (5.96 m)
deep x 9 feet (2.75 m) high.
• InSite point-to-point;
Cooling Requirements:
• TCP/IP (for system administration)
Recommended Suite Size:
The cooling requirements do not include
cooling for the room lighting, personnel or
non-CT equipment present. Cooling
requirements are listed by subsystem to allow
planning for each room of the CT suite.
Overall Suite:
Compatible Options
19.5 feet (5.96 m) wide x 24.5 feet (7.49 m)
deep x 9 feet (2.75 m) high.
• A DICOM Print Interface is standard on the
system.
• English Keyboard (B7800KE)
Exam Room: 13 feet (3.97 m) wide x 19.5
feet (5.96 m) deep.
Cooling requirements are given for minimum,
recommended and growth allowance
scenarios.
• French UIF & Keyboard (Z62401F)
Control Room: 11 feet (3.36 m) wide x 12.5
feet (3.82 m) deep.
• German UIF & Keyboard (Z62401G)
• The minimum cooling figures assume
patient throughput of 3 patients per hour and
75 scan rotations per patient.
• Italian UIF & Keyboard (Z62401H)
Equipment Room: Not required. Power
Distribution Unit heat and noise output under
all operating conditions with all available
options is low enough to allow inclusion in the
patient scanning suite with the table and
gantry.
• Spanish UIF & Keyboard (Z62401S)
•
The recommended cooling requirements
assume patient throughput limited by the
tube cooling algorithm.
• Portuguese UIF & Keyboard (Z62401P)
• ConnectPro HIS/RIS Interface with
Performed Procedure Step (PPS) M4
compatibility (B7500LN)
•
The suite cooling can be sized for future
developments by using the growth
allowance figures. This cooling will
accommodate more patients per hour and/or
potential future system enhancements.
• Bar Code Reader (B7540RB)
Temperature and Humidity:
• Volume Viewer (B7540LD)
Exam and Control Rooms: 60°-75°F (15°-
26°C) at 30%-60% relative humidity (non-
condensing).
• DentaScan (B7540LS)
• SmartScorePro (B7850PL) – Gating SW
• Prospective or retrospective EKG-gated
cardiac imaging in a single breath-hold
Equipment Room: If a separate equipment
room is used to house the PDU, the allowable
temperature range is 60°-84°F (15°-29°C) at
30%-60% relative humidity (non-condensing).
• 250-300 msec temporal resolution
* Option
