Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
4-10 Section 4-3 - General Procedure
4-3-7 B Mode Checks
4-3-7-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-28, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already)
NOTE: The keyboard layout varies from each Product, the following figures show LOGIQ e R5.x.x as
an example.
Figure 4-7 Controls available in B Mode
Figure 4-8 B Mode Screen Picture Example
SoftMenu Key
Primary Menu
Scan Area
B Mode
Zoom/Depth
Freeze
Secondary Menu
