GE LOGIQ F SERIES
D
IRECTION 5273008-100, REVISION 10 BASIC SERVICE MANUAL
Chapter 3 System Setup 3 - 17
3-6-5-3 Connect Peripherals (cont’d)
D.) Connect Foot Switch to the system.
Foot Switch can be properly connected using USB Ports.
E.) Connect the USB Memory to the system. The USB Memory can be properly connected using USB
ports.
Figure 3-11 Connect Foot Switch to the system
Figure 3-12 USB Memory Connection
1-Pedal Footswitch
3-Pedal Footswitch
