Revision D MAC 1200 resting ECG analysis system 2-25
2012250-095
Functional Description: Interfaces to Peripherals
Patient Input
The connection to the patient cable is realized with a 15-pin female sub-D
Connector, implemented on the PCB Control CS_CI directly. The mechanical
plastic housing ensures that only patient cables that have been released for use with
the MAC 1200 resting ECG analysis system system can be used.
Connector denotation: J1
Type: 15-pin sub-D, female
J1
Table 3. EKG Pin Position
Pin Number Signal Input/Output Function Definition
1 C2 Input Chest lead V2
2 C3 Input Chest lead V3
3 C4 Input Chest lead V4
4 C5 Input Chest lead V5
5 C6 Input Chest lead V6
6 Shielding Output Shielding AVSS
7 Cable Input Identification: patient cable used 0: patient cable used
8 Cable
identification
Input 5/10-pin or 12-pin cable used 0: 12-pin cable
1: 5- or 10-pin cable
9 R (RA) Input Electrode right arm
10 L (LA) Input Electrode left arm
11 F (LL) Input Electrode left leg
12 C1 Input Chest lead J1
13 NST Input Nehb electrode NST
14 N (RF) Output Electrode right leg
15 NAX Input Nehb electrode NAX
