System Test Function: Setting the Device Model
The table below shows the most important combinations:
- Language international: g, e, f, i, s, por, sw, nor, fin, dan, hol, czech, hung
- Europe 2: United Kingdom, Benelux, Scandinavia
The required device model is selected by pressing the appropriate key, 1 to 6.
Quit selection menu by pressing the X key.
Quit the self-test with X key.
MAC 1200 resting ECG analysis system configures the appropriate items and
initiates a cold start automatically. Thus, when the device is rebooted automatically
all the new settings are adopted.
Selecting a particular device model leads to the configuration of the program for
interpretation as indicated in the table above, even when the interpretation program
was configured differently beforehand as described in
“Interpretation (International
Device Models Only)” on page 3-18.
NOTE
When configuring the device model, saved ECGs are not lost.
If a new device model is selected, the program for interpretation is switched
over. When printing the saved ECGs, the display in the status line is related to
the currently enabled program for interpretation, although the results are based
on the program previously configured.
In this case, the saved ECGs should be printed out or transferred to a PC before
configuration of the new model.
Table 10. Model Combinations
Device Model Interpretation Output Formats Languages
Default Settings
Override
Function Enabled
Line Filter
1 INT HEART international international no 50 Hz
2 USA 12SL USA e yes 60 Hz
3 Europe 2 12SL international international yes 50 Hz
4 Japan 12SL international e, jap no 50 Hz
5 RUSS HEART international e,r no 50 Hz
6 Pharma 12SL USA e no 60 Hz
