Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
Requisition: 480-Z7612 - MV Shop Order: 111027-04
SWITCHGEAR SWGR-Q-B ( 15LSWGR902 )
Item:
1 Part Number: PVGX1A1A2A2202G1A1
Qty: 4 UOM: EA
Description: POWERVAC BKR PVG - POWER-VAC EQUIPMENT BREAKER
X - 15.0KV - 40KA
1 - 1200A RATING
A - RETROFIT CODE - NONE
1 - REVISION 1
A - NO CAP SWITCHING
2 - 5-CYCLE BKR
A - 60 HZ. RATING
2 - 125VDC CLOSE COIL STANDARD WIRING
2 - 125VDC TRIP COIL - 1ST
0 - NO 2ND TRIP COIL
2 - 125VDC CHARGING MOTOR
G - SEISMIC/UL LABEL/CERTIFIED TEST REPORTS
1 - NO FAST BUS TRANSFER
A - NO DIELECTRIC ENHANCEMENTS
1 - NO SPECIALS
Summary Drawing
Mark Mark Breaker Loop Tag
001 52M2 Q50 15LMBK902
001 52B1 Q51 15LFBK904
001 52B2 Q52 15LFBK908
001 52B3 Q53 15LFBK912
Device Data Sheet
Breaker Information Sheet
Sheet B
