Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
Requisition: 480-Z7612 - MV Shop Order: 111027-01
12.47KV SERVICE CENTER ADDITIONS
Item:
2 Part Number: PVGY1J1A2A2202G1A1
Qty: 1 UOM: EA
Description: POWERVAC BKR PVG - POWER-VAC EQUIPMENT BREAKER
Y - 15.0KV - 50KA
1 - 1200A RATING
J - RETROFIT CODE - 13.8kV, 750MVA, 77kA C&L
1 - REVISION 1
A - NO CAP SWITCHING
2 - 5-CYCLE BKR
A - 60 HZ. RATING
2 - 125VDC CLOSE COIL STANDARD WIRING
2 - 125VDC TRIP COIL - 1ST
0 - NO 2ND TRIP COIL
2 - 125VDC CHARGING MOTOR
G - SEISMIC/UL LABEL/CERTIFIED TEST REPORTS
1 - NO FAST BUS TRANSFER
A - NO DIELECTRIC ENHANCEMENTS
1 - NO SPECIALS
Summary Drawing
Mark Mark Breaker Loop Tag
** ** 110B 15LFBK902
Device Data Sheet
Breaker Information Sheet
Sheet B
