GE Multilin 350 - Key Components Data Sheets; Control Switches; Lockout Relays and Infrared Viewports; Auxiliary Relays, CTs, VTs, and Test Switches

Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
Drawing
Description Vendor Model Reference Marks
*
Control Switches
Breaker Control GE SB1
16SB1B9X2 52CS
*
Lockout Relay
Electroswitch Series 24 7803D 86
*
Infrared Viewport
Fluke CLKT FLK-050-CLKT 65Q
*
Aux Control Relays
GE Series RL RL4RA*****
CXA TXA RX
*
Current Transformers
Phase CT ITI Model 780 780-*** CT*
50GS ITI Model 143 143-500 CTGS*
*
Voltage Transformers
ITI PTG5 PTG5-2-110-123FF LPT
*
Test Switches
Potential ITI FT FTC-066 TS*
Current ITI FT FTC-082 TS*
* Pilot Lights
Allen Bradley 800T 800T-QTH2R IL*R Red
*
Terminal Blocks
JITE BTB BTB-671-00-06-M1 SCTB
*
Breaker Lugs
Burndy Type YA ** **
*
Fuse Holders
Shawmut USM USM2 **
*
Control Fuses
Shawmut OTM OTM **
ATM ATM **
*
Surge Arresters
GE Tranquell 9L11XPE015S LA*
**
Device Data Sheets
Key Components
Page 1 of 1
