FT & RT Test Switches
www.GEDigitalEnergy.com
Catalog Number for FT Style Switches
Catalog Number for RT Style Rack Mount Switches
Cover
Black -------- (Blank)
Clear -------- C
FT C - 074 S
Configuration
See website,
GEDigitalEnergy.com
Also on pages 8-11
Terminals
Screws ------ (Blank)
Studs -------- S
R T 2 G G 0 6 6 0 8 4 1 2 5
RT-19” Rack
Terminal
Connectors
*Screw ---------- T
Stud ----------- S
Panel Height (ref pg 7)
2 - 2 rack unit centered
3 - 3 rack unit centered
X - 3 rack unit low
H - 3 rack unit high
4 - 4 rack unit low
5 - 4 rack unit centered
6 - 4 rack unit high
Color
*ANSI 61 ------- G
ANSI 70 ------- A
Brush Al ------- B
Black ------- X
Cover
Full Length Clear ------------------ G
3 Individual Clear Covers --------- A
3 Individual Black Covers --------- B
Position # (As viewed from front)**
Left
Center
Right
000 = Blank
1
23
4
56
7
8 9 10 11 12 13 14
Left Center Right
* Denotes standard features
** See pages 8 thru 11 for 3 digit codes or go to “Configure a FT Switch” at GEDigitalEnergy.com/ITI
