GE Multilin 350 - Breaker References; Breaker Rating Table; Equipment Designation and Volume;Tab

Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
Shop Order/ Bkr
Designation Drawing Set Sheet SMY DWG Bkr Loop Tag
SWITCHGEAR SWGR-Q-A (15LSWGR901) 1110270101 B 001 52M1 Q00 15LMBK901
001 52A1 Q01 15LFBK903
001 52A2 Q02 15LFBK907
001 52A3 Q03 15LFBK911
SWITCHGEAR SWGR-Q-B (15LSWGR902) 1110270401 B 001 52M2 Q50 15LMBK902
001 52B1 Q51 15LFBK904
001 52B2 Q52 15LFBK908
001 52B3 Q53 15LFBK912
12.47KV SERVICE CENTER ADDITIONS 1110270201 B ** ** 110B 15LFBK902
Note
1
Equipment Designation Volume Tab
SWITCHGEAR SWGR-Q-A (15LSWGR901) 1 6
SWITCHGEAR SWGR-Q-B (15LSWGR902) 1 7
12.47KV SERVICE CENTER ADDITIONS 1 8
Lineup Breaker
Breaker References
The following breaker rating table is associated with the following Loop Tag Designations as outlined below:
Specific Lineup & Breaker Data is embedded in the drawing sets as listed in this sheet. Please refer to the following Tab
Sections as follows:
Reference Marks Customer Reference
