Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
Designation Shop Order
SWITCHGEAR SWGR-Q-A ( 15LSWGR901 ) 111027-01
SWITCHGEAR SWGR-Q-B ( 15LSWGR902 ) 111027-04
12.47KV SERVICE CENTER ADDITIONS 111027-01
General Procedures
Startup: Normal/Emergency
Device/System Publication/Drawing Vol. Tab
Medium Voltage Switchgear
GEK-39672
Page 36 1 3A
Medium Voltage Breakers
01.4IB.66000A
Chapter 4 1 3A
Operation: Normal/Emergency
* Refer to the publication/drawing listed below for operation of the following:
Device/System Publication/Drawing Vol. Tab
Medium Voltage Switchgear
GEK-39672
Page 36 1 3A
Medium Voltage Breakers
01.4IB.66000A
Chapter 3 1 3A
Breaker/PT Lift Cart
GEK-90214
Complete 1 3A
Breaker Test Cabinet
GEK-105263
Complete 1 3A
Ground & Test Device
GEK-90212
Complete 1 3A
Shutdown: Normal
* Open feeder breakers to disconnect loads.
*
Shutdown: Emergency
* Open each Main Breaker to remove the respective switchgear bus from upstream power system.
Location
Open each Main Breaker to remove the respective switchgear bus from upstream power system.
480-Z7612-16340-SOI
Supplemental Operational Information
Location
Operation / Maintenance
