Sludge Dewatering and Odor Control at Plant 1 Specification: 16340
Project No. P1-101 Medium Voltage Switchgear
480-Z7612-16340-SOI
Supplemental Operational Information
Equipment Function
12KV Switchgear: To distribute medium voltage power and protect facility equipment
Operating Characteristics
Vol. Tab
SWITCHGEAR SWGR-Q-A ( 15LSWGR901 ) System Voltage: 12470V 3 4A
Phase: 3P3W
kA Rating: 40kA
Main Bus: 1200A
Control Power: 125VDC
SWITCHGEAR SWGR-Q-B ( 15LSWGR902 ) System Voltage: 12470V 3 4B
Phase: 3P3W
kA Rating: 40kA
Main Bus: 1200A
Control Power: 125VDC
Limiting Conditions
Vol. Tab
SWITCHGEAR SWGR-Q-A ( 15LSWGR901 ) Maximum Voltage: 15kV 3 4A
kA Rating: 40kA
Maximum Amps: 1200A
SWITCHGEAR SWGR-Q-B ( 15LSWGR902 ) Maximum Voltage: 15kV 3 4B
kA Rating: 40kA
Maximum Amps: 1200A
Location
Location
Operation / Maintenance
