Set touchpad number and partition (94)
To set the touchpad number and partition, do the following:
1. Enter * 94.
2. Enter your program code.
3. Enter the touchpad number (see Table 2) and press *.
4. Enter the partition number and press *.
5. To exit, press #.
Add transmitters
To add transmitters to the touchpad receiver, do the following:
1. Enter * 8 at the touchpad.
2. Enter your program code (factory default is 9 7 1 3).
3. Enter the device number ( Table 2 ) and press #.
4. To load factory defaults and clear unwanted information in
memory for new installations, enter
9 1 0 # .
5. To determine the starting zone number for the specific
touchpad receiver on new installations, set the receiver zone
bank (Location 594) The bank setting is based on the zone
capabilities of both the receiver and the panel and must be
set before you add (learn) transmitters.
6. Enter 400 # to enter the sensor (transmitter) learning location.
7. Enter a zone number (1 to 192) and press *. Three beeps
from the touchpad indicates an entry error. This occurs if
you enter a transmitter number that is not within the
receiver’s zone block or if you try to learn a transmitter that
is already learned into the receiver.
Note: If you change your mind about your entry, enter 400
# 0* to terminate programming and start over from
step 6.
8. Trip the desired transmitter (within 250 seconds) as described
in
Tab le 3 . Listen for the ding dong for confirmation.
9. To program remaining transmitters, repeat steps 6 to 8.
10. To exit program mode, press EXIT EXIT.
Table 2. Device numbers
Partition
Touchpad 1 2 3 4 5 6 7 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
Table 3. Tripping transmitters
Transmitter Action
Door/window, shock, glass
guard, freeze, UFT
Activate tamper switch by removing cover.
Door/window with external
contact
Activate tamper switch by removing cover.
Feature 4—Input option 1, must be on.
Recessed door/window Activate tamper switch by removing circuit
board until tamper switch is exposed.
Micro door/window and
Micro recessed door/window
Refer to the installation instructions for the
specific sensor for activation information.
SlimLine door/window Remove cover, then press the button on
the top of the sensor, or activate the
tamper switch by removing the cover.
PIR Refer to the installation instructions for the
specific sensor for activation information.
Smoke detector without
tamper switch
Press and hold the test button.
Smoke detector with tamper
switch
Trip the tamper switch. Feature 4—Input
option 1, must be on.
Heat detector Press, then release the tamper switch.
Single button panic Press and hold the button.
Dual button panic Press and hold both buttons together.
Keyfobs Press and hold the arm and disarm
buttons together.
Repeater Press, then release the tamper switch.

GE NX-148E-RF Specifications

Power

power requirements	12.0 VDC (provided by panel)
current draw	75 mA maximum

Operating Environment

operating temperature	32° to 120°F (0° to 49°C)
storage temperature	-30° to 140°F (-34° to 60°C)
humidity	90% relative, non-condensing

Wireless Specifications

frequency	319.5 MHz
wireless range	600 feet (183 m) open air

Weight and Dimensions

dimensions	5 x 6 x 1 in. (12.7 x 15.2 x 2.5 cm)
