– 32 –
PDW8900 Series
To enter service mode, press and hold the Cookware and Heated Dry keypads simultaneously for 3 seconds.
To exit service mode, press the Start/Reset keypad at any time.
Service Mode
&1DCC>=C>?2>=CA>;?0=4;
!1DCC>=5;0C1>F43?0=4;
1>F43?0=4;B7>F=
*Note: Service mode may be used for 30 minutes maximum. After 30 minutes, the service mode will
automatically turn off.
PAD Description Time
1L Not Used
2L Activates/Deactivates Auxiliary Pump Variable
3L Activates/Deactivates Main Pump and
Single Rack Wash Motor (Wax Motor)
Variable
1R Activates/Deactivates Detergent Cup Variable
2R Activates/Deactivates Water Valve and
Smart Detergent Dispenser
Variable
3R Not Used
4R Activates/Deactivates Heater 6 min.
PAD Description Time
1L Activates/Deactivates Heater and Fan Test times out after 6 minutes.
2L Not Used
3L Activates/Deactivates Water Valve and
Smart Detergent Dispenser
Variable
4L Activates/Deactivates Detergent Cup Variable
5L Activates/Deactivates Auxiliary Pump Variable
6L Activates/Deactivates Main Pump and
Single Rack Wash Motor (Wax Motor)
Variable
PDW9700 Series and PDW9900 Series
To enter service mode, press and hold the "Down" arrow and Heated Dry keypads simultaneously for 3
seconds. To exit service mode press the Start/Reset at any time.
This dishwasher is programmed with a service mode to aid the technician in troubleshooting the dishwasher.
Each component may be cycled to detect if it is functioning correctly. Components are cycled by pressing
keypads to the right or the left of the Start/Reset keypad.
