– 45 –
Remove the support from under the evaporator
tubing.
Remove the 3 Phillips-head screws that hold
the CustomCool™ unit to the bottom of the
refrigerator compartment.
6.
7.
Move the unit to the right, then carefully pull the
left side towards the front of the refrigerator.
8.
Support
Release the 3 tabs and remove the cover.11.
Place the unit vertically on its right side.
Peel back the foam seal from the left side and
the tape from the rear of the unit.
9.
10.
Foam Seal
Tape
Damper Assembly
Heater
Thermistor
Fan
Light Bulb
(under shield)
CustomCool™ Components
To Next Page
