www.GEAppliance_com
Charcoal Filter
Me charcoal filter cannotbe cleaned.It must
be replaced. OrderPart No. WBO2X9883from
your GEsupplier.
If the model is not vented to the outside,
the air will be recirculated through a
disposable charcoal filter that helps
remove smoke and odors.
The charcoal filter should be replaced when
it is noticeably dirty or discolored (usually
after 6 to 12 months, depending on usage).
Remove2grillescrewstoremove
Ihe grille,
ToRemove the Charcoal Filter
Toremove the charcoalfl/tor'first disconnect
power at the main fuse or circuit breaker,
or pull the plug. Remove the top grille
by removing the two screws that hold it
in place.
Youmay need to openthe cabinetdoorsto
removethe screws.
Slide die filter toward die front of the oven
and remove it.
ToInstall the Charcoal Filter
Toinstall a new charcoal filter,remove
plastic and other outer wrapping from the
newfiher.
Insert the filter into the top opening of the
oven as shown, maneuvering it behind the
plastic grille until it fits squarely into place.
It will rest at an angle behind the plastic
grille on two side support tabs and in front
of die right rear tab. Replace the grille and
two screws. Reconnect power.
29
