GE prolec VR-1

GEH-7299A: Installation, Operation and Maintenance Manual
for Type VR1™ Single-Phase, Step Type Regulators
prolec.energy/prolecge 33
Without Resistor Mod
With Resistor Mod
Caution: See nameplate on regulator for jumper connection information. If nameplate on control is referred to, check to
see if nameplate on is the same as regulator. Refer to the nameplate on the regulator if they are not the same.

NN-20
NN-21
NN-22
NN-20
NN-21
NN-22
NOTE:
See
Nameplate
for
Connection
NOTE:
See
Nameplate
for
Connection
PT
Selection
Jumper
PT
Selection
Jumper
0.75 Ohm
5 Watt
Resistor
