Technical Data
DIS
C
ONN
E
C
T
P
OW
E
R
C
O
R
D
B
E
F
O
R
E
S
E
R
VI
C
ING
IM
P
O
R
TANT -
R
E
C
ONN
E
C
T A
LL
G
R
OUNDING D
E
VI
C
E
S
All parts of this appliance capable of conducting
electrical current are grounded. If grounding wires,
screws, straps, clips, nuts or washers used to
complete a path to ground are removed for service,
they must be returned to their original position and
properly fastened.
E
L
E
C
T
R
I
C
A
L
S
PE
C
I
F
I
C
ATIONS
Temperature Control (Position 5) ......................... 7-(-11 ) F
Defrost Control .......................................... 60hrs @ 45 min
w/ no door openings
Overtemperature Thermostat .............................. 140-110 F
Defrost Thermistor ........................................................ 75 F
Electrical Rating: 115V AC 60 Hz ......................... 11.6 Amp
Maximum Current Leakage ................................... 0.75 mA
Maximum Ground Path Resistance .................. 0.14 Ohms
NO
L
OAD
PE
R
F
O
R
MAN
C
E
Control Position MID/MID
and Ambient of:
...............................................70 F 90 F
Fresh Food, F ................................................ 34-40 34-40
Frozen Food, F .............................................. (-3) 3 (-3) 3
Run Time, % ...................................................... <80 80-100
R
E
F
R
IG
E
R
ATION SYST
E
M
Refrigerant Charge (R134a) ............................... 6.5 ounces
Compressor ....................................................833 BTU/hr @
3000 RPM
Minimum Compressor Capacity ......................... 22 inches
Minimum Equalized Pressure
@ 70 F ....................................................................... 40 PSIG
@ 90 F ....................................................................... 54 PSIG
IM
P
O
R
TANT SA
F
E
TY NOTI
C
E
This information is intended for use by individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt
to repair a major appliance may result in personal
injury and property damage. The manufacturer or
seller cannot be responsible for the interpretation of
this information, nor can it assume any liability in
connection with its use.
INSTA
LL
ATION
Minimum clearance required for air circulation:
TOP ............................................................................................. 1"
SIDES ................................................................................... 0.125"
REAR ........................................................................................ 0.5"
AI
R
FL
OW
E
VA
P
O
R
ATO
R
