6.4 RECORDS 6 ACTUAL VALUES
6
A trigger can be forced here at any time by setting “Yes” to the FORCE TRIGGER? command. Refer to the COMMANDS 
CLEAR RECORDS menu for information on clearing the oscillography records.
6.4.4 DATA LOGGER
PATH: ACTUAL VALUES  RECORDS  DATA LOGGER
The OLDEST SAMPLE TIME represents the time at which the oldest available samples were taken. It will be static until the log
gets full, at which time it will start counting at the defined sampling rate. The NEWEST SAMPLE TIME represents the time the
most recent samples were taken. It counts up at the defined sampling rate. If the data logger channels are defined, then
both values are static.
Refer to the
COMMANDS  CLEAR RECORDS menu for clearing data logger records.
6.4.5 BREAKER MAINTENANCE
PATH: ACTUAL VALUES  RECORDS  MAINTENANCE  BREAKER 1(6)
There is an identical menu for each of the breakers. The BKR 1 ARCING AMP values are in units of kA
2
-cycles. Refer to the
COMMANDS  CLEAR RECORDS menu for clearing breaker arcing current records. The BREAKER OPERATING TIME is
defined as the slowest operating time of breaker poles that were initiated to open.
 DATA LOGGER

OLDEST SAMPLE TIME:
2000/01/14 13:45:51
MESSAGE
NEWEST SAMPLE TIME:
2000/01/14 15:21:19
 BREAKER 1

BKR 1 ARCING AMP φA:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φB:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φC:
0.00 kA2-cyc
MESSAGE
BKR 1 OPERATING TIME
φA: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φB: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φC: 0 ms
MESSAGE
BKR 1 OPERATING
TIME: 0 ms
