CHAPTER 6: ACTUAL VALUES STATUS
T35 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-5
6
6.3.5 Teleprotection inputs
ACTUAL VALUES STATUS TELEPROTECTION INPUTS
The present state of teleprotection inputs from communication channels 1 and 2 are shown here. The state displayed is
that of corresponding remote output unless the channel is declared failed.
6.3.6 Contact outputs
ACTUAL VALUES STATUS CONTACT OUTPUTS
The present state of the contact outputs is shown here. The first line of a message display indicates the ID of the contact
output. For example, ‘Cont Op 1’ refers to the contact output in terms of the default name-array index. The second line of
the display indicates the logic state of the contact output.
For form-A contact outputs, the state of the voltage and current detectors is displayed as Off, VOff, IOff, On, IOn, and VOn.
For form-C contact outputs, the state is displayed as Off or On.
6.3.7 Virtual outputs
ACTUAL VALUES STATUS VIRTUAL OUTPUTS
The present state of up to 96 virtual outputs is shown here. The first line of a message display indicates the ID of the virtual
output. For example, ‘Virt Op 1’ refers to the virtual output in terms of the default name-array index. The second line of the
display indicates the logic state of the virtual output, as calculated by the FlexLogic equation for that output.
The T35 is provided with optional IEC 61850 capability. This feature is specified as a software option at the time
of ordering. See the Order Codes section of chapter 2 for details.
TELEPROTECTION
INPUTS
TELEPROTECTION
INPUT 1-1: Off
Range: On, Off
TELEPROTECTION
INPUT 1-16: Off
Range: On, Off
TELEPROTECTION
INPUT 2-1: Off
Range: On, Off
TELEPROTECTION
INPUT 2-16: Off
Range: On, Off
CONTACT OUTPUTS
Cont Op 1
Off
Range: On, Off, VOff, VOn, IOn, IOff
Cont Op xx
Off
Range: On, Off, VOff, VOn, IOn, IOff
VIRTUAL OUTPUTS
Virt Op 1
Off
Range: On, Off
Virt Op 96
Off
Range: On, Off
